NZXT H9 Elite Premium Dual-Chamber Mid-Tower Airflow Case - White (CM-H91EW-01)

The H9 Elite is designed to show off every angle of your build with a tempered glass top panel and a built-in RGB & Fan Controller. The unique wraparound glass design with a dual-chamber layout is the perfect showcase for premium components.

Unique uninterrupted glass panel for a clear view of the interior
Intuitive cable management and dual chamber design
Room for ten fans or three 360mm Radiators
Tempered glass top panel and included RGB & Fan Controller
Direct airflow to the GPU for handling high-powered components
Enhanced experience with other products from the NZXT ecosystem
Includes three F Series 120mm RGB Duo Fans and one F120Q Fan

GPU Capacity
The H9 Elite has 435mm of GPU clearance, offering room for the latest NVIDIA 40 Series and AMD 7000 Series cards.

Fan Capacity
The H9 Elite has room for 10 fans. With the capacity for 3x120mm fans on the side, 3 x 120mm or 2x140mm on the top and bottom, and 1 x120mm on the rear.

Radiator Capacity
The H9 Elite has room for up to a 360mm radiator on the top, bottom, or side, and up to a 120mm radiator on the rear.

Tech Specs
KEY SPECS
Motherboard Support:Mini-ITX, Micro-ATX, ATX
Enclosure Type:Mid-Tower
Case Material:SGCC Steel, TUltra-clear Tempered Glass, Dark Tinted Tempered Glass (Black only)

DIMENSIONS
Height:495mm (With Feet)
Width:290mm
Depth:466mm
Weight:13.1 kg

COMPATIBILITY & CLEARANCE
CPU Cooler Clearance:Up to 165mm
GPU Clearance:Up to 435mm
PSU Clearance:200mm
Cable Management:91mm

FRONT I/O PORTS
USB 3.2 Gen 1 Type-A:2
USB 3.2 Gen 2 Type-C:1
Headset Audio Jack:1

EXPANSION SLOTS
Standard:7
Vertical:0

DRIVE BAYS
2.5":4+2
3.5":2

FAN SUPPORT
Side:3 x 120mm
Top:3 x 120mm / 2 x 140mm
Bottom:3 x 120mm / 2 x 140mm
Rear:1 x 120mm
Filters:All Air Intakes

RADIATOR SUPPORT
Side:Up to 360mm
Top:Up to 360mm
Bottom:Up to 360mm
Rear:Up to 120mm

FAN SPECS
Model:F120Q (Case Version)
Speed:1200 ± 240RPM
Airflow:62.18 CFM
Static:1.05 mm - H2O
Noise:25.1 dBA
Fan Connector:3-pin

FAN SPECS
Model:F120RGB Duo
Speed:500 ± 1800RPM
Airflow:48.58 CFM
Static:2.42mm - H2O
Noise:29 dBA
Fan Connector:4-pin
