Minimal Footprint, Maximum Cooling: The SUP-01 Case
The Lian Li SUP-01 offers outstanding cooling performance with its unique three-chamber design, all within a compact 45-litre volume. This PC case is designed to efficiently integrate essential components like the GPU, water cooling, PSU, motherboard, CPU, and storage drives while ensuring excellent thermal performance.
Optimised Cooling: Three-Chamber Design and Powerful Fans
The SUP-01 features direct cooling for the GPU, due to its placement at the front of the case. The CPU's cooling is enhanced by the option to mount a radiator on the right side of the case, which draws in cold air through the rear opening and expels heat out the side panel. Additionally, an external 120 mm fan bracket ensures cooling for the VRM, DRAM, and M.2 areas, with heat dissipated through the top mesh panel.
Flexibility and Customisability: The Versatile Features of the SUP-01 Case
The SUP-01 supports ATX, Micro-ATX, and ITX motherboards, as well as ATX power supplies up to 220mm in length. The case includes a pre-installed PCIe 4.0 riser cable with ARGB strips for a splash of colour and allows both horizontal and vertical mounting of the GPU.
Technical Detail
Brand : Lian Li
Modal : G99.SUP01W.IN
Technical Spec
Dimensions : 403.45 x 212 x 534 mm (with feet) (L x W x H)
Material : Steel, tempered glass
Volume : 44.8 litres
Colour : White
Form factor : ATX, Micro-ATX, ITX
Pre-installed : PCIe 4.0 riser cable with aRGB strips
Maximum GPU length : 400 mm
Maximum CPU cooler height : 88.2 mm
Power supply : ATX (max. 220 mm)
Pre-installed fans : 3x 120 mm
Fan mounts
Side 1: 3x 120 mm (pre-installed)
Side 2: 3x 120 mm or 2x 140 mm
Rear exterior: 1x 120 mm
Radiator mounts:
1x 360 mm or 280 mm
Drive bays
2x 2.5-inch SSD or 2x 3.5-inch HDD (drive cage)
2x 2.5-inch SSD (behind MB tray)
Expansion slots : 4
I/O ports
1x Power button
1x Reset button
2x USB 3.0 Type-A
1x USB 3.1 Type-C
1x Audio jack
1x RGB colour control button
1x RGB mode control button
Dust filters
1x bottom
1x front
1x right side
1x top
