Key Features
3500X ARGB Mid-Tower PC Case
The CORSAIR 3500X ARGB Mid-Tower Glass PC Case combines builder-friendly features with a stunning wraparound glass aesthetic and three pre-installed RS120 ARGB fans.
Includes
- Wraparound glass view with removable front and side panels
- 3x Pre-installed RS120 ARGB fans
- Builder-friendly features for a high-performance custom PC
- Side, roof, and PSU fan mounting points for great cooling
- Compatible with ASUS BTF and MSI Project Zero reverse connection motherboards
BUILD WITHOUT BOUNDARIES
You don’t need a large footprint to build a decked-out PC. The 3500X accommodates most large graphics cards and CPU coolers, 360mm radiators, and even EATX motherboards – without taking up your entire desk.
For a truly immaculate build, the 3500X is compatible with ASUS BTF and MSI PROJECT ZERO motherboards, keeping your connections and cables out of sight.
INCLUDES RS ARGB PERFORMANCE FANS
Three RS ARGB fans deliver a one-two punch of great cooling and lighting – without complex connections. Daisy-chain your fans to just one 4-pin PWM connector and one +5V ARGB connector on your compatible motherboard.
RS Series fans incorporate CORSAIR Magnetic Dome bearings, AirGuide technology, and in-house fan blade development optimized for unparalleled cooling efficiency in both radiator and PC case applications.
COOLING PERFORMANCE
Strong cooling is paramount for a modern PC, and the 3500X excels with side, roof, and PSU fan mounts so you can cover all the angles. And with 360mm radiator mounting points in the side and roof, you’ll have plenty of potential for liquid cooling.
A BREEZE TO BUILD IN
With a modern design approach to a mainstream PC format, the 3500X has the convenient features to take the hassle out of your build.
REMOVABLE GLASS PANELS
The front and side tempered glass panels that give the 3500X its signature look are easily removable for quick access.
CABLE ROUTING
A spacious interior and roomy 38mm behind the motherboard make cable routing easy and comfortable.
STORAGE OPTIONS
A removable drive plate accommodates up to 2x HDDs and 2x SSDs simultaneously for all your storage needs.
WIDE COOLING FLEXIBILITY
Customize your cooling setup with room for up to 10x 120mm fans, plus versatile radiator mounting options including up to 360mm in the side and roof.
MODERN FRONT PANEL I/O
Puts your connections within easy reach, including a USB 3.2 Gen 2 Type-C Port, 2x USB 3.2 Gen 1 Type-A ports, and a combination audio/microphone jack.
Specification
Case Height : 506
Case Length : 460
Case Width : 240
Material : Steel, Tempered Glass
Motherboard Support : Mini-ITX, Micro-ATX, ATX, E-ATX (305mm x 277mm)
Color : BLACK
Radiator Compatibility : 120mm, 140mm, 240mm, 280mm, 360mm
Maximum GPU Length : 425mm
Maximum CPU Cooler Height : 170mm
Maximum PSU Length : 180mm
Compatible Liquid Coolers : H60, H100, H115, H150 (All Series)
Case Size : Mid-Tower
Case Power Supply : ATX
Case Expansion Slots : 7 Horizontal (or 4 Vertical)
Case Front IO : (1x) USB 3.2 Gen 2 Type-C, (2x) USB 3.2 Gen 1 Type-A, (1x) Audio in/out
Case Window : Tempered Glass
Internal 3.5" Drive Bays : 2
Internal 2.5" Drive Bays : 2
Radiator Support - Top : 360mm, 280mm, 240mm
Radiator Support - Front : None
Radiator Support - Bottom : None
Radiator Support - Side : 360mm, 280mm, 240mm
Radiator Support - Rear : 1x 120mm
Fan Support - Top : 3x 120mm; 2x 140mm
Fan Support - Front : None
Fan Support - Bottom : 3x 120mm; 1x 140mm
Fan Support - Side : 3x 120mm; 2x 140mm
Fan Support - Rear : 1x 120mm
Front IO Motherboard Connections : 1x HD Audio; 1x USB 3.2 Gen1; 1x USB-3.2 Gen2 Type-E; 1x F_PANEL
Reverse Connector Motherboard Support : Yes
Included Fans : RS ARGB Series
Dust Filtration : Yes
Cable Routing Space : 45mm
RapidRoute Included : Compatible (Sold Separately)
Left Side Panel : Tempered Glass
Right Side Panel : Steel
Vertical Mount Support : Supported (Riser Card Sold Separately)
